ASUS GX601 ROG STRIX HELIOS WHITE

Description

Product Type: Full Tower PC Case
Series: ROG Strix
Model: ASUS ROG Strix Helios GX601
Color: Black

General

Motherboard Support:

• E-ATX (Up to 12″ × 10.9″)

• ATX

• Micro-ATX

• Mini-ITX

Storage Support

Drive Bays:

• 2 × 2.5″ Dedicated Bays

• 2 × 2.5″/3.5″ Combo Bays

Expansion

Expansion Slots: 8 + 2 Vertical Expansion Slots

Front I/O

USB Ports:

• 4 × USB 3.2 Gen 1 Type-A

• 1 × USB 3.2 Gen 2 Type-C

Audio:

• 1 × Headphone / Microphone Combo Jack

Controls:

• Power Button

• Reset Button

• LED Control Button

• Fan Control Button

Radiator Support

Front:

• Up to 420mm

• 360mm

• 280mm

• 240mm

• 140mm

• 120mm

Top:

• Up to 360mm

• 280mm

• 240mm

• 140mm

• 120mm

Rear:

• 140mm

• 120mm

Cooling Support

Front:

• 3 × 140mm

• 3 × 120mm

Top:

• 3 × 140mm

• 3 × 120mm

Rear:

• 1 × 140mm

• 1 × 120mm

Pre-Installed Fans

Front:

• 3 × 140mm PWM Fans

Rear:

• 1 × 140mm PWM Fan

Clearance

Maximum CPU Cooler Height: 190mm
Maximum Graphics Card Length: 450mm (Without Front Radiator)
Maximum PSU Length: 220mm

Dust Protection

Removable Dust Filters:

• Front

• Top

• Bottom

Cable Management

Cable Management Space: 34mm Wide Cable Routing Channel with Velcro Straps and Multi-Function Cover

Dimensions & Weight

Dimensions (L × W × H): 565 × 250 × 591mm
Weight: 18kg
