CASE MSI MAG FORGE M100R

Product Type: Micro-ATX PC Case
Series: MSI MAG FORGE Series
Model: MAG FORGE M100R
Color: Black

---

General

Case Material: Steel, Plastic & Tempered Glass

Case Type: Micro-ATX Tower

Motherboard Support

• Micro-ATX
• Mini-ITX

---

Storage Support

Drive Bays

• 2 × 2.5″ SSD
• 1 × 2.5″ / 3.5″ Combo Bay
• 1 × 3.5″ HDD

---

Expansion

Expansion Slots: 4

---

Front I/O

USB Ports

• 1 × USB 3.2 Gen 1 Type-A
• 2 × USB 2.0 Type-A

Audio

• HD Audio Out

Controls

• Power Button
• Reset Button

---

Cooling Support

Front

• 3 × 120mm Fans

Top

• 2 × 120mm Fans

Rear

• 1 × 120mm Fan

---

Pre-Installed Fans

Front

• 3 × 120mm ARGB Fans

Rear

• 1 × 120mm ARGB Fan

---

Radiator Support

Front

• Up to 240mm

Top

• Up to 240mm

Rear

• Up to 120mm

---

RGB Lighting

Lighting: Addressable RGB (ARGB)

Control: Motherboard ARGB Synchronization

Software Support: Compatible with MSI Mystic Light, ASUS Aura Sync, GIGABYTE RGB Fusion, and ASRock Polychrome Sync.

---

Clearance

Maximum CPU Cooler Height: 160mm

Maximum Graphics Card Length: 300mm

Maximum Power Supply Length: 300mm (Without 3.5″ HDD Tray Installed)

---

Dust Protection

Removable Dust Filters:

• Top
• Bottom

---

Dimensions & Weight

Dimensions (D × W × H): 388 × 200 × 423mm

Net Weight: 4.14kg

Gross Weight: 5.03kg

---

Package Contents

• MSI MAG FORGE M100R Case
• 4 × Pre-installed ARGB Fans
• User Manual
• Accessories Kit
• Installation Hardware
