CASE GIGABYTE AC601G AORUS GLASS

Description

Product Type: Mid-Tower PC Case
Series: GIGABYTE AORUS C601 GLASS
Model: GB-AC601G GLOBAL
Color: Black

General

Case Material: Aluminum, Steel, Plastic & Tempered Glass
Case Type: Mid-Tower

Motherboard Support:

• Mini-ITX
• Micro-ATX
• ATX
• E-ATX

Storage Support

Drive Bays:

• 4 × 3.5″ HDD Bays
• 3 × Dedicated 2.5″ SSD Bays
• Supports up to 7 × 2.5″ SSDs (Using 3.5″ Drive Bays) (GIGABYTE)

Expansion

Expansion Slots: 8

Vertical GPU Mount: Supported (107mm Total Clearance) (GIGABYTE)

Front I/O

USB Ports:

• 1 × USB 3.1 Gen 2 Type-C
• 4 × USB 3.0 Type-A

Audio:

• HD Audio In / Out

Controls:

• Power Button
• Reset Button
• LED Control Button (GIGABYTE)

Cooling Support

Front:

• 3 × 120mm Fans
• 3 × 140mm Fans

Top:

• 3 × 120mm Fans
• 3 × 140mm Fans

Rear:

• 1 × 140mm Fan (GIGABYTE)

Pre-Installed Fans

Front:

• 3 × 140mm ARGB PWM Fans

Rear:

• 1 × 140mm ARGB PWM Fan (GIGABYTE)

Radiator Support

Front:

• Up to 420mm

Top:

• Up to 420mm

Rear:

• Up to 140mm (GIGABYTE)

RGB Lighting

Lighting: Addressable RGB (ARGB)

Controller: Built-in ARGB & PWM Hub

Software Support: GIGABYTE RGB Fusion

Hub Support:

• 6 × PWM Fan Headers
• 6 × 5V ARGB Headers (GIGABYTE)

Clearance

Maximum CPU Cooler Height: 190mm

Maximum Graphics Card Length: 420mm

Maximum Power Supply Length: 220mm (GIGABYTE)

Dust Protection

Dust Filters:

• Front
• Top
• Bottom

Panels

Front Panel: High-Airflow Mesh with Aluminum Accents

Left Side Panel: 4mm Smoked Tempered Glass (Swing-Out)

Right Side Panel: 4mm Smoked Tempered Glass (Swing-Out) (GIGABYTE)

Dimensions & Weight

Dimensions (H × W × D): 611 × 290 × 565mm

Net Weight: 21.5kg

Gross Weight: 28.15kg (GIGABYTE)

Package Contents

• User Manual
• Accessories Kit
