Name: ASUS TUF GAMING B850M-PLUS PRO AM5
Brand: ASUS
SKU: FW 030700
Price: 320000 IQD
Availability: InStock

ASUS TUF GAMING B850M-PLUS PRO AM5

(0 Reviews)

Brand: ASUS

IQD 320,000

In Stock

CPU	AMD Socket AM5 for AMD Ryzen™ 9000 & 8000 & 7000 Series Desktop Processors; Refer to https://www.asus.com/support/download-center/ for CPU support list.
Storage	Total supports 3 x M.2 slots and 4 x SATA 6Gb/s ports; AMD Ryzen™ 9000 & 7000 Series Desktop Processors; M.2_1 slot (Key M), type 2280 (supports PCIe 5.0 x4 mode); M.2_2 slot (Key M), type 2242/2260/2280 (supports PCIe 4.0 x4 mode); AMD Ryzen™ 8000 Series Desktop Processors; M.2_1 slot (Key M), type 2280 (supports PCIe 4.0 x4 mode); M.2_2 slot (Key M), type 2242/2260/2280 (supports PCIe 4.0 x4/x2 mode); AMD B850 Chipset; M.2_3 slot (Key M), type 2280 (supports PCIe 4.0 x4 mode); 4 x SATA 6Gb/s ports; Specifications vary by CPU types.; AMD RAIDXpert2 Technology; Ryzen™ 9000 Series Processors: RAID 0/1/5/10; Ryzen™ 8000 Series Processors: RAID 0/1; Ryzen™ 7000 Series Processors: RAID 0/1/10
OS	Windows 11, Windows 10 64-bit
Model	TUF GAMING B850M-PLUS
Chipset	AMD B850 Chipset
Memory	4 x DIMM slots, max. 256GB, DDR5; Supports up to 8000+MT/s (OC) with Ryzen™ 9000 & 8000 & 7000 Series Processors, ECC and Non-ECC Un-buffered DIMM; Dual channel memory architecture; Supports AMD Extended Profiles for Overclocking (EXPO™); ASUS Enhanced Memory Profile (AEMP); Adjustments will be made based on the specifications of mass-produced memory products available on the market.; * Supported memory types, data rate (speed), and number of DRAM modules vary depending on the CPU and memory configuration, for more information please refer to CPU/Memory Support list under the Support tab of product information site or visit https://www.asus.com/support/download-center/.; * Non-ECC, un-buffered DDR5 memory supports On-Die ECC function.
Graphics	1 x DisplayPort; 1 x HDMI™ port; Graphics specifications may vary between CPU types. Please refer to AMD CPU specifications.; Supports max. 8K@30Hz as specified in DisplayPort 1.4.; * Supports 4K@60Hz as specified in HDMI 2.1.
Expansion Slots	AMD Ryzen™ 9000 & 7000 Series Desktop Processors; 1 x PCIe 5.0 x16 slot (supports x16 mode); AMD Ryzen™ 8000 Series Desktop Processors; 1 x PCIe 4.0 x16 slot (supports x8/x4 mode); AMD B850 Chipset; 1 x PCIe 4.0 x1 slot; Please check the PCIe bifurcation table on the support site (https://www.asus.com/support/FAQ/1037507/).; ** Specifications vary by CPU types.; To ensure compatibility of the device installed, please refer to https://www.asus.com/support/download-center/ for the list of supported peripherals.
Ethernet	1 x Realtek 2.5Gb Ethernet; TUF LANGuard
USB	Rear USB (Total 12 ports); 1 x USB 20Gbps port (1 x USB Type-C®); 3 x USB 10Gbps ports (3 x Type-A); 4 x USB 5Gbps ports (4 x Type-A); 4 x USB 2.0 ports (4 x Type-A); Front USB (Total 7 ports); 1 x USB 10Gbps connector (supports USB Type-C®); 1 x USB 5Gbps header supports 2 additional USB 5Gbps ports; 2 x USB 2.0 headers support 4 additional USB 2.0 ports; * USB Type-C® power delivery output: max. 5V/3A.
Audio	Realtek ALC1220P 7.1 Surround Sound High Definition Audio CODEC; Impedance sense for front and rear headphone outputs; Internal audio Amplifier to enhance the highest quality sound for headphone and speakers; Supports: Jack-detection, Multi-streaming, Front Panel Jack-retasking; High quality 120 dB SNR stereo playback output and 113 dB SNR recording input (Line-in); Supports up to 32-Bit/192 kHz playback; Audio Features: Audio Shielding, Premium audio capacitors, Dedicated audio PCB layers, Audio cover, Unique de-pop circuit; Due to limitations in HDA bandwidth, 32-Bit/192 kHz is not supported for 7.1 Surround Sound audio.
Back Panel I/O Ports	1 x USB 20Gbps port (1 x USB Type-C®); 3 x USB 10Gbps ports (3 x Type-A); 4 x USB 5Gbps ports (4 x Type-A); 4 x USB 2.0 ports (4 x Type-A); 1 x DisplayPort; 1 x HDMI™ port; 1 x Realtek 2.5Gb Ethernet port; 5 x Audio jacks; 1 x BIOS FlashBack™ button
Internal I/O Connectors	Fan and Cooling Related: 1 x 4-pin CPU Fan header, 1 x 4-pin CPU OPT Fan header, 1 x 4-pin AIO Pump header, 3 x 4-pin Chassis Fan headers; Power Related: 1 x 24-pin Main Power connector, 2 x 8-pin +12V CPU Power connectors; Storage Related: 3 x M.2 slots (Key M), 4 x SATA 6Gb/s ports; USB: 1 x USB 10Gbps connector (supports USB Type-C®), 1 x USB 5Gbps header supports 2 additional USB 5Gbps ports, 2 x USB 2.0 headers support 4 additional USB 2.0 ports; Miscellaneous: 3 x Addressable Gen 2 headers, 1 x Clear CMOS header, 1 x Chassis Intrusion header, 1 x COM Port header, 1 x Front Panel Audio header (F_AUDIO), 1 x 10-1 pin Front Panel System header
Special Features	ASUS TUF PROTECTION: DIGI+ VRM (Digital power design with DrMOS), ESD Guards, TUF LANGuard, Overvoltage protection, SafeSlot, Stainless-steel back I/O; ASUS Q-Design: M.2 Q-Latch, PCIe Slot Q-Release, Q-Dashboard, Q-DIMM, Q-LED (CPU [red], DRAM [yellow], VGA [white], Boot Device [yellow green]); ASUS Thermal Solution: M.2 heatsink, VRM heatsink design; ASUS EZ DIY: BIOS FlashBack™ button, BIOS FlashBack™ LED, ProCool, Pre-mounted I/O shield, SafeDIMM; Aura Sync: Addressable Gen2 headers
Software Features	ASUS Exclusive Software: Armoury Crate (Aura Creator, Aura Sync, Fan Xpert 4, Power Saving), ASUS DriverHub, TurboV Core, TUF GAMING CPU-Z, DTS Audio Processing, Adobe Creative Cloud (Free Trial), Norton 360 for Gamers (60 Days Free Trial), WinRAR (40 Days Free Trial); UEFI BIOS: ASUS EZ DIY (ASUS CrashFree BIOS 3, ASUS EZ Flash 3, ASUS UEFI BIOS EZ Mode, ASUS MyHotkey)
BIOS	256 Mb Flash ROM, UEFI AMI BIOS
Manageability	WOL by PME, PXE
Accessories	Cables: 2 x SATA 6Gb/s cables; Miscellaneous: 1 x TUF GAMING sticker, 2 x M.2 rubber packages, 1 x Screw package for M.2 SSD; Documentation: 1 x Quick start guide
Form Factor	micro-ATX Form Factor, 9.6 inch x 9.6 inch (24.4 cm x 24.4 cm)

Product Page

ASUS TUF GAMING B850M-PLUS PRO AM5
