GIGABYTE P550SS 80 +PLUS SILVER BLACK Power Supply

Key Specifications

• Power Output: 550W

• Efficiency Certification: 80 PLUS® Silver

• Form Factor: ATX

• ATX Standard: ATX 3.0 / Compatible with ATX 3.1

• PCIe Support: PCIe 6+2 Pin

• 12V-2×6 Connector: Not Included

• Modular Design: Non-Modular

• Cooling Fan: 120mm Fluid Dynamic Bearing (FDB) Fan

• Input Voltage: 155-240V AC

• PFC Type: Active PFC (>0.9 Typical)

• 12V Rail: Single +12V Rail

• Efficiency: 90% at Typical Load (230V EU)

• MTBF: >100,000 Hours

• Power Good Signal: 100-150ms

• Hold Up Time: >16ms

• Protection Features: OVP, OPP, SCP, UVP, OCP, OTP

• Cable Type: Flat, All Black

• Color: Black

• Dimensions: 150 × 140 × 86 mm

• Warranty: 3 Years*

Connector Configuration

• 1 × 20+4-Pin ATX

• 1 × 4+4-Pin EPS/CPU

• 2 × PCIe 6+2 Pin

• 5 × SATA

• 3 × 4-Pin Peripheral (Molex)
